Dimension drawing
Dimension drawing
Technical dataApprovals
Mechanical values and environment
| Housing material | Plastic (PPS) |
| Weight | 0,02 kg |
| Ambient temperature | -25 … 60 °C |
| Degree of protection | IP67/IP69K |
| Installation orientation | Active face opposite read head |
| Tightening torque | |
| Fixing screws | max.1 Nm |
Electrical connection ratings
| Power supply | Inductive via read head |
Other
| Explosion protection | |
| ATEX | Ex II 3G Ex nL II CT70°C / Ex II 3D Ex tD A 22T70°C |
