Technical data
(Order no. 117083)
Mechanical values and environment
| Housing material | Reinforced plastic, die-cast zinc nickel-plated, stainless steel |
| Weight | |
| Net | 1,00 kg |
| Ambient temperature | -20 … 55 °C |
| Degree of protection | IP65 |
| Installation orientation | Door hinge DIN right |
Other
| Additional feature | With yellow cover |
| Product version number | V3.0.0 |
Components
117083
111739
Handle module MGB-H-AA1A5-R-111739
- Intelligent bolt tongue
- Lockout bar
- Door handle
