Switching element
| ES 502 E | Snap-action switching contact 1 NC + 1 NO |
On the usage of safety switching elements, the dog distance must be maintained to achieve the positively driven travel. The dogs must be positively mounted according to EN 1088, i.e. riveted, welded or secured in some other way against becoming loose.
LED function displayFunction display is available for the following voltage range (see accessories)
| LE110 | 110 V AC ±15% |
| Design | Upright, according to DIN 43697 |
| Housing material | Die-cast aluminum, anodized |
| Weight | |
| Net | 1,3 kg |
| Ambient temperature | -5 … 80 °C |
| Degree of protection | IP67 |
| Mechanical life | 30 x 106 |
| Contact material | Silver alloy, gold flashed |
| Switching principle | Snap-action switching contact
