Attention: The operating distance may vary depending on the background material and installation situation.
Important: Actuators must be ordered separately!
Approach directions
Typical operating distance
For a side approach direction for the actuator and read head, a minimum distance of s = 6 mm must be maintained so that the operating distance of the side lobes is not entered.
| Housing material | Reinforced thermoplastic (PBT), fully encapsulated |
| Weight | |
| Net | 0,025 kg |
| Ambient temperature | -25 … 70 °C |
| Degree of protection | IP67 |
| Installation orientation | Any |
| Tightening torque | |
| Fixing screws | max.1 Nm |
| Connection | M8 plug connector, 3-pin |
| Cable length | |
| Maximum allowed | max.25 m |
| Method of operation | Inductive |
Electrical connection ratings
| Power supply | Via evaluation unit |
| LED indicator | White: valid actuator detected |
