Important: Actuators must be ordered separately!
Installed in aluminum profile 45 x 45 mm
Typical operating distance
| Housing material | PA6 GF30 |
| Weight | |
| Net | 0,02 kg |
| Ambient temperature | -25 … 70 °C |
| Degree of protection | IP67 |
| Installation orientation | Any |
| Tightening torque | |
| Fixing screws | max.1 Nm |
| Connection | Hard-wired encapsulated connection cable |
| Cable length | |
| Maximum allowed | max.25 m |
| Method of operation | Inductive |
Electrical connection ratings
| Power supply | Via evaluation unit |
| Connecting cable | PVC, length 15m, O 4.6 mm, with crimped ferrules |
| LED indicator | White: valid actuator detected |
