| Material | Fiber glass reinforced plastic |
| Weight | |
| Net | 0,1 kg |
| Ambient temperature | |
| At UB = 24V DC | -25 … 55 °C |
| Degree of protection | IP 65 (IP 20) |
| Resilience to vibration | In acc. with EN 60947-5-3 |
| Installation orientation | Any |
| Reaction time | See operating instructions for bus module MBM-… or interlocking/locking module MGB2-I.-BR-… / MGB2-L.-BR-… |
Electrical connection ratings
| Current consumption | max.26 mA |
| Controls and indicators | |
| Switching voltage | 24 V |
| Switching current | 5 … 10 mA |
| Breaking capacity | max.0,25 W |
| Power supply LED | 24 V DC |
| Illuminated emergency stop | |
| Switching voltage | 5 … 24 V |
| Switching current | 5 … 100 mA |
| Breaking capacity | max.0,25 W |
| Power supply LED | 24 V DC |
Controls and indicators
| Control/indicator | |
| Ausfuhrung | Illuminated push buttons |
| Einlegeschild | |
| Extras | |
| Farbe | |
| Schaltelement | 1NO |
| Position | S2 |
| Control/indicator | |
| Ausfuhrung | Illuminated push buttons |
| Einlegeschild | |
| Extras | |
| Farbe | |
| Schaltelement | 1NO |
| Position | S3 |
| Control/indicator | |
| Ausfuhrung | Emergency stop |
| Einlegeschild | |
| Extras | |
| Farbe | |
| Schaltelement | 2 pos. driven NC |
| Position | S1 |
Other
| Software ID (SW-ID) | 136687 |
| Additional feature | Incl. cover set ID. No. 120344 |
Reliability values according to EN ISO 13849-1
| Illuminated emergency stop | |
| B10D | |
| Emergency stop | 0,1 x 106 |
