Important:Keys must be ordered separately!
| Housing material | PA6-GF30 |
| Weight | |
| Net | 0,13 kg |
| Ambient temperature | -20 … 70 °C |
| Degree of protection | |
| On installation in flat metal plate, thickness = 2mm | IP67 in installed state (only access side) |
| Mounting method | Fastening using screw clamp elements on rear |
| Mounting cut-out according to DIN 43700 | 33 x 68 mm |
| Installation orientation | On the front |
| Tightening torque | |
| Fixing screws in the clamping pieces on the rear | 0,25 … 0,35 Nm |
| Switching frequency | See operating instructions for the related evaluation unit |
| Connection | M8 plug connector, 3-pin |
| Cable length | |
| Maximum allowed | max.25 m |
| Method of operation | Inductive |
Electrical connection ratings
| Power supply | Via evaluation unit |
| LED indicator | White: valid actuator detected |
Work area
| Switching hysteresis | 1 mm |
| Assured switch-off distance Sar | max.30 mm |
| Assured operating distance Sao | min.2 mm |
